Linea-Lux LED Pendant

The newest addition to the Aamsco energy saving luminaire series is the NEW LINEA-LUX LED PENDANT. The Linea-lux features a timeless, minimalistic design that can complement any architectural space.
Linea-Lux LED Pendant
This uniquely designed pendant features an ultra-thin, semi-transparent optical light plate of leds to deliver even light distribution and is fully dimmable!

The Linea-Lux is manufactured with an extruded aluminum housing with die cast aluminum end caps. Powder coated silver is the standard finish.
The Linea-Lux pendant is manufactured with a diffused, polycarbonate cover that delivers a soft light with no glare. The pendant delivers a precisely controlled optimal direct & indirect light distribution between the direct surfaces below and the ambient area above the pendant.

Unique optics

The ultra-thin, semi-transparent optical light plate transmits the flux of LEDs to deliver even light distribution.

ON- Uniform Illumination

ON- Uniform Illumination

OFF - Semi-transparent optics

OFF – Semi-transparent optics

Linea-Lux LED Pendant
Unique End-to-End Mounting

The Linea-Lux unique design allows for easy in-the-field maintenance. With easy snap-together ends, you can create seamless, continuous runs.

TECHNICAL AND ORDERING DATA

Ceiling mount

Utilizes one remote constant current driver per unit, housed in a ceiling canopy.

Suspended cables

The pendant has 2 suspended cables, one to delivery power and suspension, the other for suspension only.

ETL listed for damp locations. DLC certified.

Linea-Lux LED ETL & DLC Listed
Ordering Specifications
Model No.WattsVoltsLumensColor TemperatureDimmingWarranteeDimensions
LL5050W100-277V5500lm3500K, 4000K, 5000K0-10V5 Years5.5 IN X 47.14 IN
